Ford Bronco (MOC) - (4L motors, RC electronics)
MOC - Ford Bronco RC v1.0. LEGO Technic, RC electronics FlySky, 4L motors.
Specs
- Driving: 4 PF Red L motors
- Steering: Geek Servo motor
- Gear switching: GeekServo
- Open fron differential
- Lockable rear differential (GeekServo)
- Two speed gearbox, switched by a Geek Servo motor
- Planetary wheel hubs
- 90 mm RC tyres
- No fake engine
- Custom LED lights
- Powered by 3S LiPo (3x14500)
- Curb weight: 1.8 kg
Gearing:
| Gear | Central diff | Final ratio |
|---|---|---|
| 1st | Locked | 8.48:1 |
| 2nd | Open | 5.09:1 |
Video
Photos
Radio configuration
- 1ch (steering): 100%
- 3ch (rear diff lock): 25%/64%
- 4ch (gearbpx): 20%/24%
